High Quality High Efficiency Full Automatic spray painting line coating production line glass bottle spray paint machine

DM-PT45

1. Product type: glass bottle spray painting
2. Product size: product diameter 25-120mm*H30-180mm
3.Sprocket diameter:250mm.
4. Total chain length: 45m.
5.Pitch 38.l mm
6. 585 fixtures, Interval installation
7. The line speed can be adjusted from 0.5-1.5 m/min,
8. Average output: 1200/hour
9. Heating method: electric heating, curing time 20-25 min-utes, heating temperature can be adjusted within 200 C.
10. Electricity for equipment: three-phase four-wire 380V 50-60HZ 24KW.
11.Machine size：L2300*W1750*H1850mm
12. Weight:1740kg

minimum order

1 set

Supply Ability

50set / Month

Country of Origin

China

Stock Time

30Day

Quantity:

US $37800.00 - US $38800.00 / set

Contact Now

add to cart

Guangzhou Demasha Machine Technology Co, Ltd.
DEMA Machine Founded in 2009, with over 100 employees and 10,000 sqm factory, DEMA Machinehas over 12 years experiences in Printing machine. We have own Machine R&D Team, overseasengineer service available. DM/EM service available. High strict quality inspection for each machine. Cooperation with more than 100 enterprises. Hope we can cooperate in the future
One Stop Printing Machine
Support all machines about printing in 1 stop , save your time and cost
R & D Team
TWe have own and engineer for Mechanics
Private Custom
Meet your needs to custom the machine
Output Speed
Printing output speed can be 1200pcs / Hour

Gross PowerAC 380V 50-60HZ 24KW

Automatic Grade: Automatic

Color/station: multi color multi station

Dimensions(L*W*H):L2300*W1750*H1850mm

Weight:1740 KG

Certification:ISO9001

Max. Print Area:diameter 25-120mm*H30-180mm

Warranty: 5 Years

Printing speed: 1200pcs/hr

Application area:Round, Oval, Square Bottles; Plastic, glass, metal products etc.
